Garland Commercial Ranges Ltd.
1177 Kamato Road,
Mississauga, Ontario
L4W 1X4 CANADA
General Inquires 1-905-624-0260
USA Sales, Parts and Service 1-800-424-2411
Canadian Sales 1-888-442-7526
Canada or USA Parts/Service 1-800-427-6668
36 E Series Heavy Duty
Griddle Top Range
Item: ______________________________
Quantity: __________________________
Project: ____________________________
Approval: __________________________
Date: ______________________________
36 E Series Heavy Duty Griddle Top Range
Models:
36ER38 36ES38
Specifications:
Heavy‑duty electric range, Model 36ER‑38, with griddle
top. Top consists of a one piece griddle with three
thermostatically controlled heat zones. Full size oven is
controlled by a heavy‑duty electromechanical thermostat.
Oven interior is 13.5" (343mm) high x 26.25" (667mm) wide
x 29" (533mm) deep with removable four‑position chrome
plated rack guides and one oven rack, front and rear
stainless steel grease troughs. Stainless steel front and
sides. Circuit breakers or fuses provide electric circuit
protection. Available with casters or for dais mount. Model
36ES38 has storage base in lieu of oven section.
Standard Features:
• Stainlesssteelfrontandsides
• Stainlesssteelfrontrail
• Chromeplated,4position
removable rack guides
w/oven rack
• Electro‑mechanicalheavy‑duty
oven thermostat
• 36"(914mm)griddleplate
controlled by 3 thermostat
controls 100°/450°F (38°/232°C)
• 3"(76mm)highstainlesssteel
vent raiser
• Heatresistant,cooltotouch
oven door handle
• 6"(152mm)adjustablechrome
plated legs (NSF)
• OneYearlimitedparts&labor
(USA&Canada)
Optional Features:
Stainlesssteelmainback(R&S
models)
Extra oven rack
Set of (4) Polyurethane (non‑
marking) swivel casters com‑
plete with front brakes
6"(152mm)adjustablestainless
steel legs
High voltage 460V
Marine equipment ‑ hand rails,
oven door latch, drip tray stop
and deck fasteners
NOTE: Ranges supplied with
casters must be installed with an
approved restraining device.
Model 36ER38
Thermostat Controlled
Griddle Top Range
C US
®
